Collecting Renders from a Virtual Camera

This tutorial builds on Replaying Camera Movements and shows you how to programmatically capture rendered frames from a virtual camera.

In the previous tutorial, we used the CAMERA_VIEW event handler with stream="frame" to collect rendered images. While this approach works, it offers limited control over when frames are captured. This tutorial introduces the synchronous grab_render RPC API, which gives you precise control over frame capture timing.

This tutorial will teach you how to:

Use stream="ondemand" mode for on-demand rendering
Capture frames synchronously using grab_render()
Render and retrieve depth maps

Prerequisites: Run the Recording Camera Movements tutorial first to generate the assets/camera_movement.pkl file.

Understanding Stream Modes

The CameraView component supports three streaming modes:

Mode	Description	Use Case
`frame`	Streams every rendered frame	Real-time monitoring
`time`	Streams at fixed time intervals	Periodic sampling
`ondemand`	Only renders when requested	Precise control, data collection

For data collection and synchronous workflows, stream="ondemand" is recommended because it only renders frames when you explicitly request them via grab_render().

Step 1: Load Camera Trajectory and Set Up Imports

First, we load the recorded camera matrices from the previous tutorial.

python

import cv2
import numpy as np
from asyncio import sleep, TimeoutError
from io import BytesIO
from PIL import Image as PImage

from ml_logger import ML_Logger
from pandas import DataFrame

logger = ML_Logger(root=os.getcwd(), prefix="assets")

# Load the recorded camera movement data
matrices = logger.load_pkl("camera_movement.pkl")
matrices = DataFrame(matrices)["matrix"].values.tolist()

Step 2: Create the Scene with On-Demand Rendering

We set up a scene with stream="ondemand" mode. The key difference from the previous tutorial is that no frames are transmitted until we explicitly call grab_render().

python

from vuer import Vuer
from vuer.schemas import Sphere, DefaultScene, CameraView

app = Vuer(queries=dict(grid=False))

@app.spawn(start=True)
async def main(proxy):
    # Set up the initial scene with on-demand rendering
    proxy.set @ DefaultScene(
        Sphere(key="sphere"),
        rawChildren=[
            CameraView(
                fov=50,
                width=320,
                height=240,
                key="ego",
                position=[-0.5, 1.25, 0.5],
                rotation=[-0.4 * np.pi, -0.1 * np.pi, 0.15 + np.pi],
                stream="ondemand",  # Key difference: only render when requested
                fps=30,
                near=0.45,
                far=1.8,
                renderDepth=True,  # Enable depth rendering
                showFrustum=True,
                downsample=1,
                distanceToCamera=2,
            ),
        ],
    )
    await sleep(0.0)

    # Animation loop: update scene and grab renders synchronously
    i = 0
    while True:
        i += 1

        # Calculate bouncing sphere position
        h = 0.25 - (0.00866 * (i % 120 - 60)) ** 2
        position = [0.2, 0.0, 0.1 + h]

        # Update both the sphere position and camera pose
        proxy.update @ [
            Sphere(
                key="sphere",
                args=[0.1, 20, 20],
                position=position,
                rotation=[0, 0, 0],
                materialType="standard",
                material={"roughness": 0.5, "metalness": 0.5, "color": "red"},
            ),
            CameraView(
                fov=50,
                width=320,
                height=240,
                key="ego",
                matrix=matrices[i % len(matrices)],
                stream="ondemand",
                fps=30,
                near=0.45,
                far=1.8,
                renderDepth=True,
                showFrustum=True,
                downsample=1,
                distanceToCamera=2,
                movable=False,
            ),
        ]
        await sleep(0.0)

        # Synchronously request a render from the virtual camera
        try:
            result = await proxy.grab_render(downsample=1, key="ego")
            print("\rRender received with keys:", list(result.value.keys()), end="")

            # Process RGB frame
            rgb_frame = result.value["frame"]
            rgb_pil = PImage.open(BytesIO(rgb_frame))
            rgb_img = np.array(rgb_pil)
            rgb_bgr = cv2.cvtColor(rgb_img, cv2.COLOR_RGB2BGR)

            # Process depth frame
            depth_frame = result.value["depthFrame"]
            depth_pil = PImage.open(BytesIO(depth_frame))
            depth_img = np.array(depth_pil)
            # Convert grayscale depth to BGR for side-by-side display
            if len(depth_img.shape) == 2:
                depth_bgr = cv2.cvtColor(depth_img, cv2.COLOR_GRAY2BGR)
            else:
                depth_bgr = cv2.cvtColor(depth_img, cv2.COLOR_RGB2BGR)

            # Display RGB and depth frames side by side
            combined = np.hstack([rgb_bgr, depth_bgr])
            cv2.imshow("RGB (left) | Depth (right)", combined)
            if cv2.waitKey(1) == ord("q"):
                exit()

        except TimeoutError:
            print("Render request timed out.")

Step 3: Running the Tutorial

Paste the code into grab_render_virtual_camera.py and run:

bash

python grab_render_virtual_camera.py

Open the URL printed in the terminal (usually https://vuer.ai).

You should see the camera moving through the recorded trajectory while capturing frames on-demand. An OpenCV window will display both the RGB and depth frames side by side. Press 'q' to quit.

Comparison with Event-Based Approach

Approach	Method	Control	Best For
Event-based	`CAMERA_VIEW` handler	Passive, receives all frames	Real-time streaming
On-demand	`grab_render()`	Active, request specific frames	Data collection, synchronous workflows

The grab_render() approach is particularly useful when you need to:

Ensure a frame is captured at a specific point in your simulation
Synchronize frame capture with other operations
Avoid processing unnecessary frames
